AirGradient ONE Kit Review – An open-source indoor air quality monitor

Title: AirGradient ONE Kit Review – An open-source indoor air quality monitor

Date: Wed, 29 Nov 2023 09:54:44 +0000

Desc:

The product we are reviewing today is the “AirGradient ONE” air quality monitor kit which is an updated version of the earlier AirGradient air quality monitor. The device is equipped with sensors from Sensirion and Plantower, allowing it to measure many air quality parameters such as CO2, PM2.5, TVOCs, NOx, temperature, and humidity. It is an indoor air quality monitor that is both open-source software and open hardware. This means that the Arduino source code, schematic diagrams, PCB, and 3D models of the enclosure are available to developers. AirGradient ONE DIY Kit Unboxing The device was packaged within a cardboard box, with a greeting card from the manufacturer. The card features a QR code linking to a webpage with the installation guide. Since I requested the Kit version (there’s also a fully assembled model), some sensors were not pre-assembled and they were well-packaged in separate seals. The main PCB was [...]

The post AirGradient ONE Kit Review – An open-source indoor air quality monitor appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Kumpee Teeravech

AirGradient ONE Kit Review – An open-source indoor air quality monitor

Adafruit Metro ESP32-S3 WiFi and Bluetooth IoT board comes in Arduino UNO form factor

Title: Adafruit Metro ESP32-S3 WiFi and Bluetooth IoT board comes in Arduino UNO form factor

Date: Wed, 29 Nov 2023 03:40:50 +0000

Desc:

Adafruit Metro ESP32-S3 is an IoT development board with ESP32-S3 WiFi and Bluetooth wireless SoC, 8 MB PSRAM, and 16 MB Flash that follows Arduino UNO – or Adafruit Metro – form factor. The board also comes with two STEMMA QT I2C connectors for further expansion, comes with a microSD card socket for storage, a JTAG header for advanced debugging, and supports various power options with 6-12V DC via a DC jack, 5V DC via a USB-C port, and a 2-pin connector for a LiPo battery plus the board integrates charging and battery monitoring chip. Adafruit Metro ESP32-S3 specifications: Wireless module ESP32-S3-WROOM-1 MCU – ESP32-S3 dual-core LX7 microprocessor @ up to 240 MHz with Vector extension for machine learning Memory – 8MB PSRAM Storage – 16MB SPI flash Connectivity – WiFi 4 and Bluetooth 5 with LE/Mesh PCB antenna Certifications – FCC/CE certification Storage – MicroSD card slot USB – 1x [...]

The post Adafruit Metro ESP32-S3 WiFi and Bluetooth IoT board comes in Arduino UNO form factor appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

Adafruit Metro ESP32-S3 WiFi and Bluetooth IoT board comes in Arduino UNO form factor

T-Display-S3-Long board features ESP32-S3 WiSoC, a wide touchscreen display

Title: T-Display-S3-Long board features ESP32-S3 WiSoC, a wide touchscreen display

Date: Tue, 28 Nov 2023 09:31:52 +0000

Desc:

LILYGO has designed plenty of ESP32 boards with an integrated display, but the new T-Display-S3-Long may be suitable for different applications since the ESP32-S3 board comes with a wide 3.4-inch touchscreen display with 640×180 resolution. The WiFi and Bluetooth wireless display board is powered by an ESP32-S3R8 WiSoC with 8MB PSRAM, and comes with a 16MB SPI flash, two Qwiic connectors and a 30-pin header for expansion, a USB Type-C port for power, charging, and programming, and a 2-pin connector for an optional LiPo battery. T-Display-S3-Long specifications: Wireless MCU – Espressif Systems ESP32-S3R8 dual-core Tensilica LX7 @ up to 240 MHz with vector instructions for AI acceleration, 512KB RAM, 8MB PSRAM, wireless connectivity Storage – 16MB flash (W25Q128) Connectivity via ESP32-S3 2.4 GHz 802.11 b/g/n Wi-Fi 4 with 40 MHz bandwidth support Bluetooth Low Energy (BLE) 5.0 connectivity with long-range support, up to 2Mbps data rate. Bluetooth Mesh 3D antenna [...]

The post T-Display-S3-Long board features ESP32-S3 WiSoC, a wide touchscreen display appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

T-Display-S3-Long board features ESP32-S3 WiSoC, a wide touchscreen display

WeAct ESP32H2-N4 – A $6 Bluetooth 5.2 LE, Zigbee 3.0, and Thread development board

Title: WeAct ESP32H2-N4 – A $6 Bluetooth 5.2 LE, Zigbee 3.0, and Thread development board

Date: Mon, 20 Nov 2023 08:01:25 +0000

Desc:

WeAct ESP32H2-N4 is a low-cost ESP32-H2 development board with Bluetooth 5.2 LE, Zigbee 3.0, and Thread connectivity with a design very similar to the one of Espressif Systems’ ESP32-H2-DevKitM-1 development board, but sold for just $5.70 plus shipping. The ESP32-H2 wireless microcontroller is basically the little brother of the ESP32-C6 without WiFi and aims at low-power nodes in short-range IoT networks. We have previously seen it in Espressif hardware like the aforementioned ESP32-H2-DevKitM-1 and the ESP Thread Border Router board combining ESP32-H2 & ESP32-S3 wireless chips, but so far not in third-party boards, and WeAct ESP32H2-N4 changes that. WeAct ESP32H2-N4 specifications: Wireless module – ESP32-H2-MINI-1 MCU – Espressif Systems ESP32-H2 32-bit RISC-V microcontroller at up to 96 MHz with 320 KB SRAM, 128 KB ROM, 4 KB LP memory, Bluetooth 5.2 LE/Mesh and 802.15.4 (Zigbee/Thread/Matter) radios. Storage – 4MB flash storage PCB antenna Dimensions – 13.2×16.6×2.4 mm USB – 2x [...]

The post WeAct ESP32H2-N4 – A $6 Bluetooth 5.2 LE, Zigbee 3.0, and Thread development board appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

WeAct ESP32H2-N4 – A $6 Bluetooth 5.2 LE, Zigbee 3.0, and Thread development board

International Black Friday and Cyber Monday 2023 deals and coupon codes

Title: International Black Friday and Cyber Monday 2023 deals and coupon codes

Date: Sun, 19 Nov 2023 05:32:32 +0000

Desc:

We’ve been writing about international Black Friday and Cyber Monday deals and coupon codes since 2014, as US-centric promotions such as Amazon’s Black Friday and Cyber Monday deals are not always available to the international audience of CNX Software. So once again, we’ve searched at Black Friday and Cyber Monday 2023 international promotions and discount codes from specific manufacturers as well as popular online stores such as Aliexpress, Banggood, and others. Aliexpress Black Friday and Cyber Monday event Aliexpress will have a Black Friday (and Cyber Monday) event in 2023, but we have limited details at this time since it will only start on November 23, contrary to some of the other deals we’ll feature below which are already up and running. But the event will have two periods: Nov 20-22 PT – Warm Up event where users can find and add items to the cart before purchasing during the [...]

The post International Black Friday and Cyber Monday 2023 deals and coupon codes appeared first on CNX Software - Embedded Systems News.

Category: Alibaba T-Head

Source: Jean-Luc Aufranc (CNXSoft)

International Black Friday and Cyber Monday 2023 deals and coupon codes

LILYGO T-Display S3 Pro – A 2.33-inch ESP32-S3 color touchscreen display with enclosure

Title: LILYGO T-Display S3 Pro – A 2.33-inch ESP32-S3 color touchscreen display with enclosure

Date: Thu, 16 Nov 2023 11:08:52 +0000

Desc:

LILYGO T-Display S3 Pro is another ESP32-S3 powered WiFi and Bluetooth display from the company with a 2.33-inch color touchscreen LCD, a plastic enclosure, support for USB-OTG, two QWIIC connectors, and a 470 mAh battery. We’re told the T-Display S3 Pro is an update to the T-Display S3 (and by extension of the T-Display S3 Touch and T-Display S3 AMOLED models) but the display is quite bigger at 2.33-inch and with higher resolution (480×222), it comes with an ABS case with an integrated battery by default, adds support for USB OTG, and also includes a few sensors that are missing from the earlier models. T-Display S3 Pro specifications: Wireless MCU – Espressif Systems ESP32-S3R8 dual-core Tensilica LX7 @ up to 240 MHz with vector instructions for AI acceleration, 512KB RAM, 8MB PSRAM, wireless connectivity Storage – 16MB flash, microSD card slot Connectivity via ESP32-S3 2.4 GHz 802.11 b/g/n Wi-Fi 4 [...]

The post LILYGO T-Display S3 Pro – A 2.33-inch ESP32-S3 color touchscreen display with enclosure appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

LILYGO T-Display S3 Pro – A 2.33-inch ESP32-S3 color touchscreen display with enclosure

Nordic introduces nRF7002 EK WiFi 6 Arduino Shield, nRF7000 SSID-based Wi-Fi locationing chip

Title: Nordic introduces nRF7002 EK WiFi 6 Arduino Shield, nRF7000 SSID-based Wi-Fi locationing chip

Date: Thu, 16 Nov 2023 07:26:26 +0000

Desc:

Nordic Semi has launched the nRF7002 EK based on the company’s nRF7002 dual-band WiFi 6 IoT chip and in the form of an Arduino shield that works with other Nordic development kits such as the nRF52840 DK, nRF5340 DK, and nRF9160 DK, and separately, the company launched the nRF7000 SSID-based Wi-Fi locationing chip. nRF7002 EK Earlier this year, the company launched the nRF7002 DK, a complete development kit with the nRF7002 WiFi 6 chip and the nRF5340 dual-core Arm Cortex-M33 wireless microcontroller, but for developers who already own nRF devkits, they’ve now introduced the nRF7002 EK Arduino Shield. nRF7002 EK specifications: Wireless chip – Nordic Semi nRF7002 Dual-band Wi-Fi 6 (802.11ax) WiFi station mode Target Wake Time (TWT) 20 MHz channel bandwidth Antenna – 2.4 and 5 GHz antenna for WiFi SWF port for RF measurement Host interface – SPI or QSPI interfaces Dimensions – Arduino shield form factor The [...]

The post Nordic introduces nRF7002 EK WiFi 6 Arduino Shield, nRF7000 SSID-based Wi-Fi locationing chip appeared first on CNX Software - Embedded Systems News.

Category: Hardware

Source: Jean-Luc Aufranc (CNXSoft)

Nordic introduces nRF7002 EK WiFi 6 Arduino Shield, nRF7000 SSID-based Wi-Fi locationing chip

Giveaway Week 2023 – Elecrow ESP32 Terminal with a 3.5-inch touchscreen display and OV2640 camera

Title: Giveaway Week 2023 – Elecrow ESP32 Terminal with a 3.5-inch touchscreen display and OV2640 camera

Date: Sat, 11 Nov 2023 03:00:28 +0000

Desc:

If I remember correctly, Elecrow sent me an end-of-year gift with a notebook (paper style), a pen, and a 3.5-inch ESP32 terminal. I had completely forgotten about it, and while wondering what I would give for Giveaway Week 2023, and looking around in drawers and on shelves, I found an “ESP32 Terminal” package, and I was like “What the F is that and where is it coming from?”. Long story short, the 6th prize of this year’s giveaway week is Elecrow’s ESP32 Terminal with a 3.5-inch touchscreen display that also comes with a front-facing OV2640 camera and six Crowtail connectors for expansion plus a LiPo battery connector. Elecrow ESP32 terminal specifications: Wireless module – ESP32-S3 2.4 GHz Wi-Fi and Bluetooth 5 (LE) module with 16MB flash and 8MB PSRAM Storage – MicroSD card slot Display – 3.5-inch TFT LCD display with 480×320 resolution (ILI9488 driver), capacitive touchscreen Camera – 2MP [...]

The post Giveaway Week 2023 – Elecrow ESP32 Terminal with a 3.5-inch touchscreen display and OV2640 camera appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

Giveaway Week 2023 – Elecrow ESP32 Terminal with a 3.5-inch touchscreen display and OV2640 camera

Giveaway Week 2023 – WisBlock IoT Starter Kit with LoRaWAN and LTE-M/NB-IoT or GSM connectivity

Title: Giveaway Week 2023 – WisBlock IoT Starter Kit with LoRaWAN and LTE-M/NB-IoT or GSM connectivity

Date: Wed, 08 Nov 2023 03:00:40 +0000

Desc:

RAKwireless is joining CNX Software Giveaway Week for the third year running with the company offering a free WisBlock IoT Starter Kit with LoRaWAN and LTE-M/NB-IoT or GSM connectivity following giveaways for the WisBlock Kit 2 LoRa-based GPS Tracker with Solar Panel in 2021 and RAK Developer Kit (Air Quality Kit) in 2022. The WisBlock IoT Starter Kit enables prototyping with LoRaWAN and cellular IoT connectivity plus display modules (OLED and RGB) and plenty of sensors such as accelerometers, light sensors, VOC sensors, temperature and humidity sensors, and more. WisBlock IoT Starter Kit content: 1x RAK4631 WisBlock Core module SoC – Nordic nRF52840  Arm Cortex-M4F microcontroller @ 64 MHz with 1 MB Flash, 256 KB RAM, Bluetooth Low Energy 5.0 protocol stack LoRaWAN – Semtech SX1262 LoRa Transceiver with LoRaWAN 1.0.2 protocol stack (supports Class A & C), global coverage support: RU864, IN865, EU868, US915, AU915, KR920, AS923 1x RAK11200 [...]

The post Giveaway Week 2023 – WisBlock IoT Starter Kit with LoRaWAN and LTE-M/NB-IoT or GSM connectivity appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

Giveaway Week 2023 – WisBlock IoT Starter Kit with LoRaWAN and LTE-M/NB-IoT or GSM connectivity

ESP32 Arduino Core 3.0.0 adds support for ESP32-C6 and ESP32-H2

Title: ESP32 Arduino Core 3.0.0 adds support for ESP32-C6 and ESP32-H2

Date: Fri, 03 Nov 2023 10:03:14 +0000

Desc:

Espressif Systems has now released an alpha version of ESP32 Arduino Core 3.0.0 enabling the new ESP32-C6 and ESP32-H2 targets to be programmed with the Arduino IDE, and including a number of new features made possible by the ESP-IDF 5.1 SDK. Announced in 2021, the ESP32-C6 WiFi 6, Bluetooth 5 LE, and 802.15.4 wireless MCU became available in modules and devkits at the beginning of this year, but so far they could only be programmed with the latest version (5.1) of the ESP-IDF framework, and so was the new ESP32-H2 Bluetooth 5.2 and 802.15.4 (Zigbee/Thread) MCU. But fans of Arduino programming can now rejoice as an alpha version of ESP32 Arduino Core 3.0.0 brings support for the new microcontroller, and a stable release is planned for December 2023. But as you can probably imagine ESP32 Arduino Core 3.0.0 will also bring lots of other changes since the ESP32 Arduino Core [...]

The post ESP32 Arduino Core 3.0.0 adds support for ESP32-C6 and ESP32-H2 appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

ESP32 Arduino Core 3.0.0 adds support for ESP32-C6 and ESP32-H2

RAKwireless Blues.ONE LoRaWAN, LTE-M and NB-IoT devkit ships with Blues NoteCard including a 500MB data plan

Title: RAKwireless Blues.ONE LoRaWAN, LTE-M and NB-IoT devkit ships with Blues NoteCard including a 500MB data plan

Date: Wed, 01 Nov 2023 10:01:38 +0000

Desc:

RAKwireless Blues.ONE is a LoRaWAN IoT development kit that also supports LTE-M and NB-IoT cellular connectivity through the Blues NoteCard which comes with 10 years and an upgradeable 500MB cellular data plan. The devkit relies on the WisBlock modular IoT prototyping system with the RAK13102 WisBlock Blues Notecarrier, the Blues NoteCard, a WisBlock Base Board, and a WisBlock Core module. It can be used to prototype or develop IoT devices for industrial automation and asset-tracking applications. Blues.ONE specifications: RAK4631 WisBlock Core Module SoC – Nordic nRF52840  Arm Cortex-M4F microcontroller @ 64 MHz with 1 MB Flash, 256 KB RAM, Bluetooth Low Energy 5.0 protocol stack LoRaWAN – Semtech SX1262 LoRa Transceiver with LoRaWAN 1.0.2 protocol stack (supports Class A & C), global coverage support: RU864, IN865, EU868, US915, AU915, KR920, AS923 RAK19007 WisBlock Base Board 4x Sensor Slots 1x IO Slot 1x USB Type C connector Rechargeable battery connector Solar [...]

The post RAKwireless Blues.ONE LoRaWAN, LTE-M and NB-IoT devkit ships with Blues NoteCard including a 500MB data plan appeared first on CNX Software - Embedded Systems News.

Category: Hardware

Source: Jean-Luc Aufranc (CNXSoft)

RAKwireless Blues.ONE LoRaWAN, LTE-M and NB-IoT devkit ships with Blues NoteCard including a 500MB data plan

Review of RaZberry 7 Pro Z-Wave Raspberry Pi HAT and Z-Uno2 Z-Wave board

Title: Review of RaZberry 7 Pro Z-Wave Raspberry Pi HAT and Z-Uno2 Z-Wave board

Date: Sun, 29 Oct 2023 01:00:58 +0000

Desc:

Z-Wave.Me has sent us a couple of Smart Home devices based on Z-Wave technology for review, namely the RaZberry 7 Pro Raspberry Pi HAT and the Z-Uno2 board. The Swiss company has primarily developed Z-Wave products for years and is a member of the Z-Wave Alliance. For those who are concerned about the issues of signal interference in the 2.4GHz range (WiFi, Zigbee, Bluetooth, and Thread), Z-Wave technology is an excellent choice because it operates on a less congested frequency range of 800-900MHz and the technology has been around for more than 20 years, resulting in a wide variety of Z-Wave devices available in the market, and they can work well together across different brands due to a proper certification process which is another advantage when compared to other protocols. The two devices we received are RaZberry 7 Pro, which is a shield that plugs into the 40-pin GPIO header [...]

The post Review of RaZberry 7 Pro Z-Wave Raspberry Pi HAT and Z-Uno2 Z-Wave board appeared first on CNX Software - Embedded Systems News.

Category: Hardware

Source: Paisit Wongsongsarn

Review of RaZberry 7 Pro Z-Wave Raspberry Pi HAT and Z-Uno2 Z-Wave board

The Portenta Hat Carrier board adds Raspberry Pi HAT support to the Portenta X8 SBC

Title: The Portenta Hat Carrier board adds Raspberry Pi HAT support to the Portenta X8 SBC

Date: Wed, 25 Oct 2023 17:01:12 +0000

Desc:

The Arduino Portenta Hat Carrier board aims to interface the Linux-capable Portenta X8 board with the vast ecosystem of Raspberry Pi HAT (Hardware on Top) expansion boards. Introduced last year, the Arduino Portenta X8 is the first Arduino Pro hardware that can run Linux thanks to its NXP i.MX 8M Mini Arm Cortex-A53 quad-core processor. But it comes in a tiny 66.04 x 25.4 mm form factor which may be great for integration into products, but for prototyping or design of products such as IoT gateways, the company has now launched the Portenta Hat Carrier that enables the board to easily connect with the Raspberry Pi HATs available today. Portenta Hat Carrier specifications: Compatible with the Portenta X8 board and future Portenta with the same high-density connectors Storage – MicroSD card slot Camera I/F – MIPI CSI camera connector (CNXSoft: Arduino does not explicitly say whether it’s compatible with the [...]

The post The Portenta Hat Carrier board adds Raspberry Pi HAT support to the Portenta X8 SBC appeared first on CNX Software - Embedded Systems News.

Category: Hardware

Source: Jean-Luc Aufranc (CNXSoft)

The Portenta Hat Carrier board adds Raspberry Pi HAT support to the Portenta X8 SBC

Review of MaTouch ESP32-S3 Rotary IPS Display with a 2.1-inch round touchscreen display

Title: Review of MaTouch ESP32-S3 Rotary IPS Display with a 2.1-inch round touchscreen display

Date: Sun, 22 Oct 2023 11:33:13 +0000

Desc:

The product we are reviewing today is the “MaTouch ESP32-S3 Rotary IPS Display with Touch 2.1” ST7701″ from Makerfabs which offers an alternative to the MaTouch_ESP32-S3 4-inch Display Demo Kit that we reviewed a few months ago. Just like the earlier model, the new kit is equipped with an ESP32-S3-WROOM-1-N16R8, featuring 16MB of flash memory and 8MB of PSRAM. This device supports both Wi-Fi and Bluetooth 5.0 wireless communication and offers connectivity options through I2C and UART ports for interfacing with external devices. The display features a round IPS panel with a resolution of 480×480 pixels, capacitive touch capability, and LVGL library support. Additionally, it includes a mechanical rotary encoder and supports press operations. MaTouch ESP32-S3 Rotary IPS Display specifications Controller: ESP32-S3-WROOM-1, PCB Antenna, 16MB Flash, 8MB PSRAM, ESP32-S3-WROOM-1-N16R8 Wireless: Wi-Fi and Bluetooth 5.0 LCD: 2.1-inch High Lightness IPS,65K color LCD Driver: ST7701S FPS: > 70 Resolution: 480×480 LCD interface: [...]

The post Review of MaTouch ESP32-S3 Rotary IPS Display with a 2.1-inch round touchscreen display appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Kumpee Teeravech

Review of MaTouch ESP32-S3 Rotary IPS Display with a 2.1-inch round touchscreen display

M5Stack Cardputer – A $30 card-sized ESP32-S3 computer with display and keyboard

Title: M5Stack Cardputer – A $30 card-sized ESP32-S3 computer with display and keyboard

Date: Fri, 13 Oct 2023 17:01:03 +0000

Desc:

M5Stack Cardputer is a card-sized portable computer based on the ESP32-S3-powered M5Stamp S3 wireless module and equipped with a 56-key keyboard and 1.14-inch TFT display, plus some sensors and peripheral expansion ports. At first, it’s hard to imagine what it could be used for apart from being a hardware hacking toy, but the company says the card-sized WiFi computer can be used for rapid functional verification, industrial control, and home automation systems. M5Stack Cardputer specifications: Wireless MCU module – M5Stack M5Stamp S3 with SoC – Espressif Systems ESP32-S3FN8 dual-core 32-bit Xtensa LX7 microcontroller with AI vector instructions up to 240MHz, RISC-V ULP co-processor, 512KB SRAM, 2.4GHz WiFi 4 (802.11b/g/n), Bluetooth 5.0 BLE + Mesh, 8MB flash 2.4GHz 3D antenna USB – 1x USB Type-C port Expansion connectors for I/Os such as SPI, I2C, UART, ADC, and more Storage – MicroSD card socket Display – 1.14-inch IPS LCD with 240×135 resolution [...]

The post M5Stack Cardputer – A $30 card-sized ESP32-S3 computer with display and keyboard appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

M5Stack Cardputer – A $30 card-sized ESP32-S3 computer with display and keyboard

49 cents “Black Pill” board clone features AT32 Cortex-M4F microcontroller

Title: 49 cents “Black Pill” board clone features AT32 Cortex-M4F microcontroller

Date: Tue, 10 Oct 2023 01:00:02 +0000

Desc:

The “Black Pill” board with an STM32F4 Cortex-M4F MCU is already cheap, but I’ve just come across a clone going for just 49 cents plus shipping (34 cents to Thailand) based on a 240 MHz AT32 (or AT32F4) Cortex-M4F microcontroller with Arduino support. [Edit: the price looks like a lottery and everybody seems to get a different price, and not related to VAT. See comments section] Other features are pretty much the same with two 20-pin headers for GPIOs, an SWD header, a USB Type-C port for power and programming, and a few buttons. WeAct “Black Pill” board specifications: Microcontroller – Artery Technology AT32F403ACGU7 Cortex-M4F MCU @ 240MHz with 96 + 128KB RAM, 256KB zero wait-state flash, 768KB non-zero wait-state flash; note: RAM and flash size are somehow configurable by the user, and the numbers listed here are the maximum capacities. Storage – Footprint for SPI flash USB – 1x [...]

The post 49 cents “Black Pill” board clone features AT32 Cortex-M4F microcontroller appeared first on CNX Software - Embedded Systems News.

Category: Hardware

Source: Jean-Luc Aufranc (CNXSoft)

49 cents “Black Pill” board clone features AT32 Cortex-M4F microcontroller

Waveshare RP2040-PiZero – A Raspberry Pi RP2040 board with Raspberry Pi Zero form factor

Title: Waveshare RP2040-PiZero – A Raspberry Pi RP2040 board with Raspberry Pi Zero form factor

Date: Mon, 09 Oct 2023 14:51:51 +0000

Desc:

Waveshare RP2040-PiZero board is a Raspberry Pi Zero lookalike that features a Raspberry Pi RP2040 microcontroller instead of a Linux-capable application processor. But RP2040 board comes with the same layout as the Raspberry Pi Zero and similar ports including two USB Type-C ports, a mini HDMI/DVI connector, a microSD card slot, and a 40-pin GPIO header, but also adds support for LiPo batteries with a 2-pin connector and a charging circuit. RP2040-PiZero specifications: MCU – Raspberry Pi RP2040 dual-core Cortex M0+ microcontroller @ 133 MHz with 264 kB of embedded SRAM Storage – 16MB SPI flash, microSD card slot Video – Mini HDMI port that can output DVI signals USB – 1x USB Type-C port for data using PIO-USB host/device implementation Expansion – 40-pin color-coded header with 2x SPI, 2x I2C, 2x UART, 4x 12-bit ADC, 16x PWM, 8x Programmable I/O (PIO) state machines for custom peripheral support Misc – [...]

The post Waveshare RP2040-PiZero – A Raspberry Pi RP2040 board with Raspberry Pi Zero form factor appeared first on CNX Software - Embedded Systems News.

Category: Hardware

Source: Jean-Luc Aufranc (CNXSoft)

Waveshare RP2040-PiZero – A Raspberry Pi RP2040 board with Raspberry Pi Zero form factor

M5Dial – An ESP32-S3 smart rotary knob with a touchscreen display

Title: M5Dial – An ESP32-S3 smart rotary knob with a touchscreen display

Date: Sun, 08 Oct 2023 01:00:09 +0000

Desc:

M5Stack M5Dial is a WiFi and Bluetooth-connected smart rotary knob with a round 1.28-inch touchscreen TFT display powered by an ESP32-S3 board, more precisely, the M5Stamp S3 IoT module. The user-programmable device comes with a rotary encoder recording the position and direction of the knob, an RFID module, an RTC, a buzzer, and under-screen buttons, as well as two Grove connectors for expansion enabling all sorts of projects. M5Dial specifications: Wireless MCU module – M5Stack M5Stamp S3 with SoC – Espressif Systems ESP32-S3FN8 dual-core 32-bit Xtensa LX7 microcontroller with AI vector instructions up to 240MHz, RISC-V ULP co-processor, 512KB SRAM, 2.4GHz WiFi 4 (802.11b/g/n), Bluetooth 5.0 BLE + Mesh, 8MB flash 2.4GHz 3D antenna USB – 1x USB Type-C port Expansion connectors for I/Os such as SPI, I2C, UART, ADC, and more Display – 1.28-inch TFT display with 240×240 resolution using GC9A01 driver, and FT3267 capacitive touchscreen controller RFID – [...]

The post M5Dial – An ESP32-S3 smart rotary knob with a touchscreen display appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

M5Dial – An ESP32-S3 smart rotary knob with a touchscreen display

Inkplate 4 TEMPERA ePaper display supports ESPHome, Arduino, and MicroPython (Crowdfunding)

Title: Inkplate 4 TEMPERA ePaper display supports ESPHome, Arduino, and MicroPython (Crowdfunding)

Date: Wed, 04 Oct 2023 01:00:23 +0000

Desc:

Years after years, Soldered Electronics keeps on churning out new ESP32-powered ePaper displays and the latest model is the Inkplate 4 TEMPERA with a recycled 3.8-inch e-paper touchscreen with 600×600 resolution and plenty of sensors and features for a device of that size. The InkPlate 4 TEMPERA comes with a frontlight, a gyroscope, an accelerometer, temperature, humidity, air quality, and gesture sensors, Wi-Fi and Bluetooth connectivity, a built-in battery, and a low-power operating mode. Inkplate 4 TEMPERA specifications: Wireless module – ESP32-WROVER-E with ESP32 dual-core microcontroller with Wi-Fi 4 & Bluetooth 4.0 connectivity Memory – 8MB PSRAM Storage – 4MB flash PCB antenna Storage – MicroSD card slot Display (ED038TH2) 3.8-inch 3-bit grayscale (black, white, and six shades of gray) ePaper display with 600 x 600 pixels resolution Refresh rate 0.18s partial refresh rate in 1-bit (B&W) mode 0.86s full refresh mode in either 1-bit or 3-bit modes Multi-point touchscreen [...]

The post Inkplate 4 TEMPERA ePaper display supports ESPHome, Arduino, and MicroPython (Crowdfunding) appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

Inkplate 4 TEMPERA ePaper display supports ESPHome, Arduino, and MicroPython (Crowdfunding)

Arduino GIGA R1 WiFi board gets touchscreen display shield

Title: Arduino GIGA R1 WiFi board gets touchscreen display shield

Date: Fri, 29 Sep 2023 13:04:51 +0000

Desc:

The Arduino GIGA Display Shield is a 3.97-inch RGB touchscreen display designed for the Arduino GIGA R1 WiFi board introduced a few months ago with an STM32H7 dual-core Cortex-M7/M4 microcontroller and a Murata 1DX module for WiFi 4 and Bluetooth 5.1 connectivity. Besides featuring an 800×480 touchscreen display, the new shield offers some other features such as an MP34DT06JTR digital microphone, a Bosch BMI270 six-axis IMU, a 20-pin Arducam camera connector, and an RGB LED. Arduino GIGA Display Shield (ASX00039) specifications: Display – 3.97-inch touchscreen display with 800×480 resolution (model: KD040WVFID026-01-C025A),  16.7 million colors, 5-point touch, connected over I2C Camera I/F – 20-pin ArduCam camera connectors Sensors Bosch SensorTech BMI270 6-axis IMU with 16-bit tri-axial gyroscope and a 16-bit tri-axial accelerometer STMicro MP34DT06JTR MEMS microphone Misc -1x RGB LED (I2C) Supply Voltage – 3.3V Dimensions – 106 x 80 mm The new shield can be mounted to the GIGA R1 [...]

The post Arduino GIGA R1 WiFi board gets touchscreen display shield appeared first on CNX Software - Embedded Systems News.

Category: Hardware

Source: Jean-Luc Aufranc (CNXSoft)

Arduino GIGA R1 WiFi board gets touchscreen display shield

LILYGO T-ETH-Lite – An ESP32-S3 board with Ethernet, optional PoE support

Title: LILYGO T-ETH-Lite – An ESP32-S3 board with Ethernet, optional PoE support

Date: Wed, 27 Sep 2023 01:00:39 +0000

Desc:

LILYGO T-ETH-Lite ESP32-S3 is a new ESP32-S3 WiFi and Bluetooth development board with a low-profile Ethernet RJ45 connector using a WIZnet W5500 Ethernet controller, supporting PoE with an extra shield, and also equipped with a microSD card socket and expansion I/Os. ESP32-based development boards with Ethernet have been around for years including LILYGO’s own “TTGO T-Lite W5500“, but so far we haven’t many based on the more recent ESP32-S3 microcontroller except for the SB Components’ ESPi board that we covered last April. But LILYGO T-ETH-Lite ESP32-S3 adds another cost-effective board with Ethernet. LILYGO T-ETH-Lite ESP32-S3 specifications: Wireless module ESP32-S3-WROOM-1 MCU – ESP32-S3 dual-core LX7 microprocessor @ up to 240 MHz with Vector extension for machine learning Memory – 8MB PSRAM Storage – 16MB SPI flash Connectivity – WiFi 4 and Bluetooth 5 with LE/Mesh PCB antenna Storage – MicroSD card slot Connectivity 802.11 b/g/n WiFi 4 up to 150 Mbps and [...]

The post LILYGO T-ETH-Lite – An ESP32-S3 board with Ethernet, optional PoE support appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

LILYGO T-ETH-Lite – An ESP32-S3 board with Ethernet, optional PoE support

Sparkfun launches cheaper no-code “DataLogger IoT” board compatible with Qwiic modules

Title: Sparkfun launches cheaper no-code “DataLogger IoT” board compatible with Qwiic modules

Date: Sat, 16 Sep 2023 02:13:27 +0000

Desc:

Last May, SparkFun introduced the “Datalogger IoT – 9DoF” no-code platform with support for over 50 Qwiic sensor modules and a built-in 9-axis IMU sensor and magnetometer. Taking into consideration that some users may not make use of the built-in sensors, the company decided to launch a cheaper version called the “DataLogger IoT” that can still get data from Qwiic sensor and GPS modules without any programming thanks to the “no-code” Arduino firmware preloaded on the ESP32-WROOM-32E module. SparkFun DataLogger IoT specifications: Wireless module – ESP32-WROOM-32E with: ESP32 dual-core microcontroller 4MB flash 2.4 GHz WiFi and Bluetooth LE connectivity, built-in PCB antenna Storage – MicroSD card slot USB – 1x USB Type-C port for power and configuration via CH340C Expansion – 2x Qwicc I2C connectors for sensors and/or GPS module Misc Boot and Reset buttons Status and charging LED, WS2812 RGB LED Jumpers to enable/disable LEDs, I2C pull-up resistors, and [...]

The post Sparkfun launches cheaper no-code “DataLogger IoT” board compatible with Qwiic modules appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

Sparkfun launches cheaper no-code “DataLogger IoT” board compatible with Qwiic modules

SparkFun launches ESP32-based “Arduino IoT Weather Station” with Arduino IoT Cloud integration

Title: SparkFun launches ESP32-based “Arduino IoT Weather Station” with Arduino IoT Cloud integration

Date: Sun, 03 Sep 2023 07:58:27 +0000

Desc:

SparkFun’s Arduino IoT Weather Station is a complete weather station kit leveraging the company’s MicroMod ecosystem with an ESP32 Processor Board and various sensors and developed in collaboration with Arduino for integration into their IoT Cloud service. Most people will check the weather on the Internet or watch the weather forecast on TV, but if you live in a remote area with a micro-climate or just want to have fun building your own weather station, the latest SparkFun kit will allow you to monitor temperature, air and soil humidity, wind speed and direction, lightning, and rainfall data at home and monitor the data from anywhere using a web browser. Arduino IoT Weather Station kit content: MicroMod ESP32 Processor module MicroMod Weather Carrier Board with a BME280 temperature, pressure, and humidity sensor and an AS3935 lightning detector only. The optional VEML6075 UV sensor is NOT included. The Weather Meter Kit with [...]

The post SparkFun launches ESP32-based “Arduino IoT Weather Station” with Arduino IoT Cloud integration appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

SparkFun launches ESP32-based “Arduino IoT Weather Station” with Arduino IoT Cloud integration

TRACEPaw sensorized paw helps legged robots “feel the floor” with Arduino Nicla Vision

Title: TRACEPaw sensorized paw helps legged robots “feel the floor” with Arduino Nicla Vision

Date: Thu, 24 Aug 2023 09:36:29 +0000

Desc:

Our four-legged friends don’t walk on tarmac the same way as they do on ice or sand as they can see and feel the floor with their eyes and nerve endings and adapt accordingly. The TRACEPaw open-source project, which stands for “Terrain Recognition And Contact force Estimation through Sensorized Legged Robot Paw“, aims to bring the same capabilities to legged robots. Autonomous Robots Lab achieves this through the Arduino Nicla Vision board leveraging its camera and microphone to run machine learning models on the STM32H7 Cortex-M7 microcontroller in order to determine the type of terrain and estimate the force exercized on the leg. But the camera is apparently not used to look at the terrain, but instead, at the deformation of the silicone hemisphere – made of “Dragon Skin” – at the end of the leg to estimate 3D force vectors, while the microphone is used to recognize terrain types [...]

The post TRACEPaw sensorized paw helps legged robots “feel the floor” with Arduino Nicla Vision appeared first on CNX Software - Embedded Systems News.

Category: Hardware

Source: Jean-Luc Aufranc (CNXSoft)

TRACEPaw sensorized paw helps legged robots “feel the floor” with Arduino Nicla Vision

Setting up a private LoRaWAN network with WisGate Connect gateway

Title: Setting up a private LoRaWAN network with WisGate Connect gateway

Date: Sun, 20 Aug 2023 08:01:10 +0000

Desc:

In this guide, we’ll explain how to set up a private LoRaWAN network using the Raspberry Pi CM4-based RAKwireless’ WisGate Connect gateway and Docker or Portainer to install NodeRED, InfluxDB, Grafana, and other packages required to configure our gateway. The WisGate Connect is quite a versatile gateway with Gigabit and 2.5Gbps Ethernet plus several optional wireless connectivity options such as LoRaWAN, 4G LTE, 5G, WiFi 6, Zigbee, WiFi HaLoW, and more that can be added through Mini PCIe or M.2 sockets, expansion through WisBlock IO connectors and a 40-pin Raspberry Pi HAT connector. We’ll start by looking at the gateway features in detail, but if you already know all that, you can jump to the private LoRaWAN network configuration section. WisGate Connect unboxing, specifications, and teardown RAKwireless sent us a model with a Raspberry Pi CM4 equipped with 4 GB of RAM and 32 GB of eMMC memory, GPS and [...]

The post Setting up a private LoRaWAN network with WisGate Connect gateway appeared first on CNX Software - Embedded Systems News.

Category: Broadcom BCMxxxx

Source: Jean-Luc Aufranc (CNXSoft)

Setting up a private LoRaWAN network with WisGate Connect gateway

Raspberry Pi Pico to Arduino Uno adapter relies on “FlexyPins” for castellated holes

Title: Raspberry Pi Pico to Arduino Uno adapter relies on “FlexyPins” for castellated holes

Date: Wed, 09 Aug 2023 09:48:59 +0000

Desc:

Solder Party’s “Raspberry Pi Pico to Uno FlexyPin Adapter” transforms the Raspberry Pi Pico into an Arduino UNO without soldering the board directly or using headers, but instead relying on FlexyPins flexible pins to attach the Pico board to the adapter using its castellated holes. The end result is basically the same as for the WisdPi ArduPico board, except the Raspberry Pi Pico is soldered to the main PCB on the latter, but it can be easily removed from the Solder Party’s Uno adapter board to be replaced with another compatible model, e.g. Raspberry Pi Pico vs Pico W. The FlexyPins can be used with any board or module with castellated holes, but it’s obviously especially useful for castellated modules without through holes, for example, to easily program a bunch of ESP32 modules. You’ll first need to get a few FlexyPins as shown below. Then solder them to a compatible [...]

The post Raspberry Pi Pico to Arduino Uno adapter relies on “FlexyPins” for castellated holes appeared first on CNX Software - Embedded Systems News.

Category: Hardware

Source: Jean-Luc Aufranc (CNXSoft)

Raspberry Pi Pico to Arduino Uno adapter relies on “FlexyPins” for castellated holes

SunFounder Zeus Car Kit review – A fun toy and Arduino learning tool

Title: SunFounder Zeus Car Kit review – A fun toy and Arduino learning tool

Date: Sun, 06 Aug 2023 17:01:39 +0000

Desc:

SunFounder Zeus Car Kit is an Arduino UNO and ESP32 Cam-based educational kit for children (and adults) that can be used to learn more about electronics, robotics, and programming. It’s a car comprised of four 6cm Mecanum wheels for omnidirectional motion and various sensors that can be controlled with an Android app enabling first-person view (FPV) thanks to the built-in camera. The company sent us a Zeus Car Kit for review and evaluation, and after assembly, we’ll use it in “Play Mode”, or in other words a toy that basically works out of the box, before checking out the “Programing Mode” and related Arduino tutorials to evaluate it’s educational potential. Zeus Car Kit Unboxing The kit comes in a nice retail package which highlights some of the capacities of the kit: FPV, Omnidrive, AI vision, compass, IR control, APP control, and RGB lights. The package itself contains four more boxes [...]

The post SunFounder Zeus Car Kit review – A fun toy and Arduino learning tool appeared first on CNX Software - Embedded Systems News.

Category: Atmel AVR

Source: Jean-Luc Aufranc (CNXSoft)

SunFounder Zeus Car Kit review – A fun toy and Arduino learning tool

eModGATE Moduino X0 – An ESP32-based industrial IoT controller with battery support

Title: eModGATE Moduino X0 – An ESP32-based industrial IoT controller with battery support

Date: Thu, 03 Aug 2023 10:24:22 +0000

Desc:

TECHBASE eModGATE Moduino X0 is an industrial IoT control based on a choice of ESP32 modules from Espressif and Pycom, equipped with a battery slot for remote installations, and various interfaces to connect sensors or actuators via RS232, RS485, and/or digital I/Os. We first wrote about TECHBASE Moduino-X series ESP32 IoT endpoints almost six years ago with the X1 and X2 models, but since then the company has added more models such as the large X3 and X4 devices with more I/Os, and the new entry-level Moduino X0 that’s similar to the X1, but with battery support instead of a supercapacitor. eModGATE Moduino X0 specifications: ESP32 wireless module/board options ESP32-WROVER with ESP32 dual-core Tensilica LX6 processor @ 240 MHz, 8MB PSRAM, 4MB or 16MB SPI flash Pycom WiPy 3.0 with 4MB RAM, 8MB Flash Pycom SiPy with 512kB RAM, 4MB Flash, Sigfox Pycom LoPy with 4MB RAM, 8MB Flash, Wi-Fi/BT4.2, [...]

The post eModGATE Moduino X0 – An ESP32-based industrial IoT controller with battery support appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

eModGATE Moduino X0 – An ESP32-based industrial IoT controller with battery support

12 Euros ESP32-S3-DevKit-LiPo board runs Linux 6.3

Title: 12 Euros ESP32-S3-DevKit-LiPo board runs Linux 6.3

Date: Sat, 29 Jul 2023 03:50:14 +0000

Desc:

Olimex ESP32-S3-DevKit-LiPo is a new open-source hardware ESP32-S3 board with 8MB flash, 8MB PSRAM, as well as LiPo battery and JTAG support that can run Linux 6.3, or the more traditional Arduino or MicroPython firmware. The board is based on the ESP32-S3-WROOM-1-N8R8 module, features two USB-C ports for power, programming, and JTAG debugging, plenty of expansion with two rows of I/Os plus a pUEXT connector, Reset and Boot buttons, and a couple of LEDs. ESP32-S3-DevKit-LiPo specifications: Wireless module – Espressif ESP32-S3-WROOM-1-N8R8 with SoC – ESP32-S3 dual-core LX7 microprocessor @ up to 240 MHz with Vector extension for machine learning, WiFi 4 & Bluetooth 5 LE/Mesh Memory – 8MB OSPI PSRAM Storage – 8MB QSPI flash PCB antenna Dimensions – 25.5 x 18.0 x 3.1 mm USB 1x USB Type-C OTG port also used for JTAG/Serial 1x USB Type-C port for USB-serial programming and power Expansion 2x 22-pin GPIO headers pUEXT [...]

The post 12 Euros ESP32-S3-DevKit-LiPo board runs Linux 6.3 appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

12 Euros ESP32-S3-DevKit-LiPo board runs Linux 6.3

RP2 Nano is a $6.6 Raspberry Pi RP2040 board with Arduino Nano form factor

Title: RP2 Nano is a $6.6 Raspberry Pi RP2040 board with Arduino Nano form factor

Date: Wed, 26 Jul 2023 08:03:27 +0000

Desc:

ArtronShop RP2 Nano board features the Raspberry Pi RP2040 microcontroller in the Arduino Nano form factor in a way that’s much cheaper than the official Arduino Nano RP2040 Connect board. That’s possible because Thailand-based AtronShop did not include all the bells and whistles such as WiFi and Bluetooth connectivity, sensors, and used a smaller flash. So the RP2 Nano basically offers the same I/Os and features as the Arduino Nano, but the Microchip ATmega328 8-bit AVR microcontroller gives place to the more powerful Raspberry Pi RP2040 dual-core Cortex-M0+ MCU plus 2MB flash, and the board also adds an extra Grove connector for expansion. RP2 Nano specifications: MCU – Raspberry Pi RP2040 dual-core Cortex M0+ microcontroller @ 133 MHz with 264 kB of embedded SRAM Storage – 2MB SPI flash USB – 1x USB Type-C OTG port for power, data, and programming Expansion Arduino Nano headers (2x 15-pin headers) Up to [...]

The post RP2 Nano is a $6.6 Raspberry Pi RP2040 board with Arduino Nano form factor appeared first on CNX Software - Embedded Systems News.

Category: Hardware

Source: Jean-Luc Aufranc (CNXSoft)

RP2 Nano is a $6.6 Raspberry Pi RP2040 board with Arduino Nano form factor

Flipper Zero hardware & wireless hacking tool gets an app “store” with open-source app

Title: Flipper Zero hardware & wireless hacking tool gets an app “store” with open-source app

Date: Tue, 25 Jul 2023 14:24:43 +0000

Desc:

Flipper Zero portable multi-tool for pentesters and hardware hackers has now gotten an app “store” with currently around 100 free and open-source apps available through the device’s Android or iOS app. I missed it at the time, but the Flipper Zero launched on Kickstarter in July 2020 and was massively popular with close to 5 million dollars raised from almost 38,000 backers. The tool looks like a toy but it allows hacking with GPIOs and short-range wireless protocols such as Bluetooth, RFID, NFC, and infrared. Flipper Zero specifications: Wireless MCU  – STMicro STM32WB55RG with Arm Cortex-M4 application core @ 64 MHz, Arm Cortex-M0+ network core @ 32 MHz, 1024 KB flash, 256KB SRAM Storage – MicroSD card slot up to 64GB Display – 1.4-inch monochrome LCD (black on orange background) with 128×64 resolution via ST7565R SPI display controller Connectivity Bluetooth 5 LE & 802.15.4 via STM32WB55 microcontroller Bluetooth LE – [...]

The post Flipper Zero hardware & wireless hacking tool gets an app “store” with open-source app appeared first on CNX Software - Embedded Systems News.

Category: Hardware

Source: Jean-Luc Aufranc (CNXSoft)

Flipper Zero hardware & wireless hacking tool gets an app “store” with open-source app

ButtonBoard is a 3cm round WiFi IoT board with BME280 and IMU sensors (Crowdfunding)

Title: ButtonBoard is a 3cm round WiFi IoT board with BME280 and IMU sensors (Crowdfunding)

Date: Mon, 24 Jul 2023 08:04:19 +0000

Desc:

ButtonBoard is a tiny round-shaped board based on the ESP-01F WiFi IoT module (ESP8285), equipped with a BME280 air pressure, humidity, and temperature sensor, an IMU sensor, and designed for wearables electronics projects. ButtonBoard specifications: Wireless module – ESP-01F module with ESP8285 Tensilica L106 microcontroller @ 80/160 MHz with 2.4GHz WiFi connectivity, PCB antenna; package: 11 x 10 mm USB – Micro USB port Sensors Bosch Sensortec BME280 pressure, temperature, and humidity sensor, and altimeter. IMU sensor Expansion – Through holes for up to 10x GPIOs, I2C, SPI, USART Misc – Reset button Power Supply – 5V via micro USB port; onboard power management Dimensions – About 3cm diameter The ButtonBoard can be programmed with the Arduino IDE via USB or WiFi, MicroPython, Lua, and Scratch, and they also mention support for ChatGPT through the current API, but I could not find any code samples at this time. They do [...]

The post ButtonBoard is a 3cm round WiFi IoT board with BME280 and IMU sensors (Crowdfunding) appeared first on CNX Software - Embedded Systems News.

Category: Espressif

Source: Jean-Luc Aufranc (CNXSoft)

ButtonBoard is a 3cm round WiFi IoT board with BME280 and IMU sensors (Crowdfunding)
